Grillo G 52 [12/70] Putting the machine into service

Translation of the Original Instructions

TECHNICAL SPECIFICATIONS G52

ENGINES

ROBIN SUBARU EX17, 169 cc, 5 HP @ 3600 r.p.m., one-cylinder petrol engine

KOHLER 3000, 196 cc, 5,5 HP @ 3600 r.p.m., one-cylinder petrol engine

MACHINE

Recoil starter

Fuel tank capacity: 3,7 lt. (EX17 – KOHLER 3000)

Gearbox: oil-bath gears, one forward gear and one reverse gear.

P.T.O.: 644 r.p.m. anticlockwise in walking tractor version – 965 r.p.m. clockwise in sickle-bar

version.

Implement quick coupling: 50 mm Ø

Safety devices: active coupling (by releasing the levers on the handlebar, both the wheels and the

implement will stop immediately)

Rotary tiller: 500 mm standard and adjustable at 370 mm.

Tilling depth: 130 mm.

Handlebar: side and height adjustable, reversible and mounted on shock-absorbers.

Gears Speeds with tyres 13×5.00-6 (km/h)

Forward (walking tractor)

Reverse (walking tractor)

Forward (sickle-bar)

Reverse (sickle-bar)

1,4

2,2

1,4

Track: external measurements with tyres 13×5.00-6 > 400 mm

Attachments: 86 cm mulching cutting bar, 96 cm double cutting bar, 50 cm rotary cutter, 80 cm

pivoting front blade, furrower behind the tiller, 50 and 85 mm wheel extensions, snow chains, 80

cm pivoting and tilting sweeper.

PUTTING THE MACHINE INTO SERVICE

1) Check that the machine has not been damaged during transport.

2) Remove the walking tractor from its packaging paying attention not to damage levers and

cables. Use a lifting machine (capacity: 200 kg).

3) The walking tractor is delivered with the handlebar bent over the engine (sickle-bar version). If

the handlebar is to be used with the rotary tiller push the lever (fig. 9) and slowly turn the handlebar

180°, paying attention not to damage the cables.

4) Before connecting the attachment grease both the PTO and the 3-teeth coupling, then mount

the attachment (e.g. rotary tiller, cutting bar) by completely inserting the attachment into the

coupling of the walking tractor (fig. 4). To fix the attachment turn the lever of the quick coupling into

position “BLOCCATO” (LOCKED – fig. 5, A).

5) Add engine oil (please refer to the appropriate manual).

6) Check oil in the gearbox (fig. 6). If necessary add 80W90 oil, quantity 750 gr.

7) Add oil into the oil-bath air filter (for versions provided with this type of filter), use the same oil

type as the engine oil (fig. 6, n. 4).

8) Verify the tyre pressure according to the table provided.

TYRE PRESSURE

13x5.00-6 2 PLY RATING 2,2 BAR

9) Fill the tank with fuel using a funnel provided with a fine filter.

10) Check the various liquid level with the machine in horizontal position.

Grillo G 52 [12/70] Putting the machine into service
