Princess9/ Translation of the original instructions

RECOMMENDED SPARE PARTS TO HAVE AT DISPOSAL

1 set of belts

1 engine air filter

1 throttle lever

TECHNICAL SPECIFICATIONS M1 – MR MODELS

MODEL: PRINCESS M1 (single speed) PRINCESS MR (1 FORWARD SPEED + 1 REVERSE

SPEED)

ENGINE: HONDA GX160 OHV 163 cm 4,8 HP (@ 3600 r.p.m.), one cylinder, petrol.

– ROBIN SUBARU EX17 169 cm 5 HP (@ 3600 r.p.m.), one cylinder, petrol.

– KOHLER SH 265 196 cm 5,5 HP (@3600 r.p.m.), one cylinder, petrol.

STARTER: pull-starting system with recoil starter.

FUEL TANK: 3,1 L (GX160) – 3,6 L (EX17 / SH 265).

HOURLY CONSUMPTION: 1,4 L (GX160) – 1,5 L (EX17) – 1,7 (SH 265).

GEARBOX: single speed (M1) – one forward speed plus one reverse speed (MR).

FINAL DRIVE: with pinion and chain.

CLUTCH: with lever control on the handlebar working on the belt tensioner.

HANDLEBAR: with height and side adjustment.

ROTARY TILLER CASING: bolted pressed steel.

ROTARY TILLER RPM: I° gear 132 r.p.m. (M1) - I° gear 160 r.p.m. – reverse gear 36 r.p.m.

(MR).

STANDARD ROTARY TILLER: with six hoes and side discs for total width of 800 mm (ﾱ31.5’’)

HOES DIAMETRE: Ø 320 mm ( Ø 13’’).

WORKING AREA WIDTH WITHOUT SIDE DISCS: adjustable at 300-520-700 mm.

WORKING AREA DEPTH: 320 mm.

SAFETY DEVICES: machine cut-out on release; guards, handlebars in compliance with the law;

muffler protection.

FRONT TRANSFER WHEEL AS A STANDARD FEATURE.

ATTACHMENTS: furrower, transfer wheels for rotary tiller.

TECHNICAL SPECIFICATIONS MP3 – MP3 PRO

ENGINE: HONDA GX 160 OHC 163 cc 4,8 HP (@ 3600 r.p.m.), one-cylinder petrol.

KOHLER SH 265 196 cc 5,5 HP (@ 3600 r.p.m.), one-cylinder petrol.

ROBIN SUBARU EX 17 OHC 169 cc 5HP (@ 3600 r.p.m.), one-cylinder petrol.

HONDA GX 200 OHV, 196 cc, 5,5 HP (@ 3600 r.p.m.), one-cylinder petrol.

STARTER: pull-starting system with automatic rewind.

FUEL TANK: 3,1 L (GX 160 – GX 200)- 3,6 L (EX17/SH265).

HOURLY CONSUMPTION: 1,4 litres (GX160) – 1,5 litres (EX17) – 1,7 litres (GX200 – SH265)

GEARBOX: 2 forward gears + 1 reverse gear, gears in oil bath
