Grillo Princess M1 [12/64] Instructions for use

Princess9/ Translation of the original instructions

FINAL DRIVE: with pinion and chain.

CLUTCH: with lever control on the handlebar working on belt tensioner.

HANDLEBAR: with height and side adjustment.

ROTARY TILLER CASING: bolted and in pressed steel.

STANDARD ROTARY TILLER: with six tines and side discs for a total width of 800mm – MP3

PRO: 27 mm hexagonal shaft with six tines and side discs for a total width of 970 mm.

TINES DIAMETER: 320 mm – MP3 PRO 330 mm

WORKING AREA without side discs: adjustable at 300 – 520- 770 mm – MP3 PRO adjustable

at 560 – 820 mm.

WORKING AREA DEPTH: 320 mm – MP3 PRO 330 mm

TILLER RPM: I° gear 36 r.p.m.- II° gear 160 r.p.m. – reverse gear 36 r.p.m.

SAFETY DEVICES: the machine stops automatically when user releases the handlebars; guards,

handlebars complying with current law; silencer-protection.

STANDARD FEATURE: front transfer wheel.

ATTACHMENTS: furrower, plough kit, transfer wheels for rotary tiller Ø 42X4 cm.

PUTTING THE MACHINE INTO SERVICE

- Check that the machine has not been damaged during transport.

- Fix the two tiller elements (fig.5).

- Fit the transfer wheel (fig. 1 – fig. 2 – fig.3, no. 6) using the spring.

- Fix the spur (fig.1 – fig. 2 – fig. 3, no. 3)

- Fit the fenders (fig. 1, no. 12 – fig. 2 – fig. 3, no. 13).

- Fill the engine oil up to level (always refer to the engine manual).

INSTRUCTIONS FOR USE

BEFORE STARTING THE ENGINE

- fill the tank with fuel.

- check that the air filter is clean.

- check the engine oil level.

STARTING THE ENGINE

- Set the throttle lever in STARTER position. If the engine is cold, turn the starter lever to CHOKE

(always refer to the engine manual).

- Start the engine by pulling the pull-start handle (fig.1 no.6).

- Once the engine is running return the starter lever to RUN and the throttle lever almost to the

minimum setting.

STARTING WORK

- Adjust the height and lateral position of the handlebar to get the best working position using the

knob (fig. 1 – fig. 2 – fig. 3, n. 2)

- Adjust the working depth by lowering or raising the rear foot (fig. 1 – fig. 2 – fig. 3, no. 3)

- Pull the transfer wheel support down and raise to showed position (fig. 1 – fig. 2 – fig. 3, no. 7).

- Speed up the engine (fig. 1 – fig. 2 – fig. 3, no. 1)

- Slowly press the forward lever (fig. 1 – fig. 2 – fig. 3, no. 1) until the machine starts moving.

In the MR model pull the RM lever to engage the reverse gear. Safety device: if this lever is

released even accidentally, the machine stops.
