SILICON PLANAR SWITCHING DIODE
BAS16
SOT-23
Formed SMD Package
Marking
BAS16 = A6
High-Speed Switching Diodes
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION SYMBOL UNIT
Continuous Reverse Voltage
V
R
V
Repetitive Peak Reverse Voltage
V
RRM
V
Forward Current (DC)
I
F
mA
Repetitive Peak Forward Current
I
FRM
mA
Non Repetitive Peak Forward Current
(Per Crystal)
t=1µµs
I
FSM
A
t=1ms
I
FSM
A
t=1s
I
FSM
A
Power Dissipation @ T
a
=25ºC P
D
W
Storage Temperature Range
T
stg
o
C
Junction Temperature
T
j
o
C
Thermal Resistance
Junction to Ambient in free fair
R
th (j-a)
K/W
ELECTRICAL CHARACTERISTICS (T
a
=25º C unless specified otherwise)
DESCRIPTION SYMBOL TEST CONDITION MIN TYP MAX UNIT
Forward Voltage
V
F
I
F
= 1 mA
0.715 V
I
F
= 10 mA
0.855
I
F
= 50 mA
1.0
I
F
= 150 mA
1.25
Reverse Voltage Leakage Current
I
R
V
R
=25V, T
j
=150ºC
30
µ
A
V
R
=75V
1.0
µ
A
V
R
=75V, T
j
=150ºC
50
µ
A
Diode Capacitance
C
d
V
R
=0V, f=1MHz
2.0 pF
Forward Recovery Voltage When
Switched to
V
fr
I
F
=10mA, t
P
=20ns
1.75 V
Reverse Recovery Time When Switched
from
t
rr
I
F
=10mA to
I
R
=60mA, R
L
100 Ω,
measured at I
R
=1mA
4.0 ns
Recovery Charge When Switched from
Q
S
I
F
=10mA to V
R
=5V,
R
L
=100 Ω,
45 pC
BAS16 Rev_1 270304E
1.0
500
VALUE
75
85
150
- 55 to +150
0.5
215
500
0.25
4.0
Pin Configuration
1 =
2 = NC
3 =
ANODE
CATHODE
3
1
2
Continental Device India Limited
Data Sheet Page 1 of 3
Continental Device India Limited
An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company
