NPN SILICON PLANAR TRANSISTORS 2N4237, 2N4238
2N4239
TO-39
Metal Can Package
ELECTRICAL CHARACTERISTICS (T
a
=25ºC unless specified otherwise)
SMALL SIGNAL CHARACTERISTICS
DESCRIPTION SYMBOL TEST CONDITION MIN TYP MAX UNIT
Collector Emitter Saturation Voltage
*V
CE (sat)
I
C
=500mA, I
B
=50mA
0.3 V
I
C
=1A, I
B
=0.1A
0.6 V
Base Emitter Saturation Voltage
*V
BE (sat)
I
C
=1A, I
B
=0.1A
1.5 V
Base Emitter On Voltage
*V
BE (on)
I
C
=250mA, V
CE
=1V
1.0 V
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
C
obo
V
CB
=10V, I
E
=0,
f=0.1MHz
100 pF
Small Signal Current Gain
h
fe
I
C
=100mA, V
CE
=10V,
f=1KHz
30
Current Gain High Frequency
lh
fe
|
I
C
=100mA, V
CE
=10V,
f=1MHz
1.0
*Pulse Test: Pulse Width < 300µµs, Duty Cycle < 2%
2N4237_4239Rev121004E
Continental Device India Limited
Data Sheet Page 2 of 4
