NPN SILICON PLANAR SWITCHING TRANSISTORS
2N2221 2N2222
TO-18
Metal Can Package
General Purpose Transistor
ABSOLUTE MAXIMUM RATINGS
DESCRIPTION
SYMBOL
Collector Emitter Voltage
V
CEO
Collector Base Voltage
V
CBO
Emitter Base Voltage
V
EBO
Collector Current Continuous
I
C
Power Dissipation @ T
a
=25ºC P
D
Derate Above 25ºC
Power Dissipation @ T
c
=25ºC P
D
Derate Above 25ºC
Operating And Storage Junction
Temperature Range
T
j
, T
stg
ELECTRICAL CHARACTERISTICS (T
a
=25ºC unless specified otherwise )
DESCRIPTION
SYMBOL
TEST CONDITION
MIN
TYP
MAX
Collector Emitter Voltage
*V
CEO
I
C
=10mA, I
B
=0
30 V
Collector Base Voltage
V
CBO
I
C
=10µA, I
E
=0
60 V
Emitter Base Voltage
V
EBO
I
E
=10µA, I
C
=0
5 V
Collector Cut Off Current
I
CBO
V
CB
=50V, I
E
=0
10 nA
V
CB
=50V, I
E
=0,
T
a
=150ºC
10
µA
Collector Cut Off Current
I
EBO
V
EB
=3V, I
C
=0
10 nA
2N2221 2N2222
DC Current Gain
h
FE
*I
C
=0.1mA, V
CE
=10V
>20 >35
I
C
=1mA, V
CE
=10V
>25 >50
*I
C
=10mA, V
CE
=10V
>35 >75
*I
C
=150mA, V
CE
=10V
40 - 120 100 - 300
*I
C
=150mA, V
CE
=1V
>20 >50
*I
C
=500mA, V
CE
=10V
>20 >30
*Pulse Test: Pulse Width
<
300
µµ
s, Duty Cycle
<
2%
2N2221_2222Rev_1 310303E
UNIT
V
V
V
mA
mW
mW/ ºC
W
800
500
2.85
1.2
VALUE
30
60
5
6.85
- 65 to +200
mW/ ºC
ºC
Continental Device India Limited
Data Sheet Page 1 of 4
Continental Device India Limited
An ISO/TS16949 and ISO 9001 Certified Company
