NPN SILICON PLANAR SWITCHING TRANSISTORS 2N2221 2N2222
TO-18
Metal Can Package
ELECTRICAL CHARACTERISTICS (T
a
=25ºC unless specified otherwise)
SMALL SIGNAL CHARACTERISTICS
DESCRIPTION SYMBOL TEST CONDITION MIN TYP MAX UNIT
Collector Emitter Saturation Voltage
*V
CE (sat)
I
C
=150mA, I
B
=15mA
0.4 V
I
C
=500mA, I
B
=50mA
1.6 V
Base Emitter Saturation Voltage
*V
BE (sat)
I
C
=150mA, I
B
=15mA
1.3 V
I
C
=500mA, I
B
=50mA
2.6 V
Transition Frequency
**f
T
I
C
=20mA, V
CE
=20V,
f=100MHz
250 MHz
Output Capacitance
C
obo
V
CB
=10V, I
E
=0,
f=100KHz
8.0 pF
Input Capacitance
C
ibo
V
BE
=0.5V, I
C
=0,
f=100KHz
30 pF
SWITCHING TIME
DESCRIPTION SYMBOL TEST CONDITION MIN TYP MAX UNIT
Delay Time
t
d
10 ns
Rise Time
t
r
25 ns
Storage Time
t
s
225 ns
Fall Time
t
f
60 ns
*Pulse Test: Pulse Width < 300µµs, Duty Cycle < 2%
** f
T
is defined as the frequency at which Ih
fe
I extrapolates to unity
2N2221_2222Rev_1 310303E
I
C
=150mA, I
B1
=15mA,
V
CC
=30V, V
BE(off)
=0.5V
I
C
=150mA, I
B1
=
I
B2
=15mA, V
CC
=30V
Continental Device India Limited
Data Sheet Page 2 of 4
