DACO SEMICONDUCTOR CO., LTD.
®
DACMI160N1200
◆
V
DSS
= 1200V
◆ Fully Avalanche Rated
◆ Pb Free & RoHS Compliant
Parameter Symbol Ratings Unit
Drain-Source Voltage V
DS
1200 V
Gate-Source Voltage V
GS
-5/+20 V
Drain Current-Continuous
C
I
C°52=
D
168
110
A
Drain Current-Pulsed
@ T
C
=25° C
Note1
I
DM
400 A
Maximum Power Dissipation P
D
580 W
Storage Temperature Range T
STG
-50 to +150 ° C
T egnaR erutarepmeT noitcnuJ gnitarepO
J
-50 to +150 ° C
Thermal Resistance, Junction-to-Case R
JC
0.22 ° C/W
www.dacosemi.com.tw
- 1 -
Silicon Carbide Enhancement Mode MOSFET
Features
Applications
Absolute Maximum Ratings (Tc=25°C unless otherwise noted)
◆
R
DS(ON)
θ
< 20mΩ@ V = 20 V
GS
VIsolation Voltage (A.C. 1 minute)
iso
4000 V
MMounting torque (M5 Screw)
d
3-5 N
m
◆ Isolation Type Package
◆ Electrically Isolation base plate
Jan 2018
@ T
C
C°100= @ T
◆ Power Converters
◆ Motor Drive
◆ Solar Inverters ◆ Switch Mode Power Supplies
◆ Battery Chargers
Dimensions in inches and (millimeters)
SOT-227
G
S
S
D
Preliminary
G
A
D
H
C
K
I
F
O
E
J
M
ØL
NB
P
DIMENSIONS
DIM
MM
INCHES
MIN
MXA
MIN
MXA
.500
.307
.029
.077
1.487
1.250
.931
.996
.586
.492
.161
.161
.181
.165
1.184
.519
.322
.033
.082
1.502
1.258
.956
1.007
.594
.516
.169
.169
.191
.177
1.192
12.70
7.80
.75
1.95
37.80
31.75
23.65
25.30
14.90
12.50
4.10
4.10
4.60
4.20
30.10
13.60
8.20
.84
2.10
38.20
32.00
24.30
25.60
15.10
13.10
4.30
4.30
4.95
4.50
30.30
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
M4*8
