EWAP400~540MBYNN
Packaged air-cooled water chillers
4PW22679-1B
Operation manual
4
■
Compressor thermal protectors
The compressor motors are equipped with thermal protectors
(Q*M). The protectors are activated when the compressor motor
temperature becomes too high. When temperature returns to
normal, the protectors reset automatically, but the controller
needs to be reset manually.
■
Fan motor thermal protector
The condenser fan motors are equipped with thermal protectors
(Q*F). The protectors are activated when the temperature
becomes too high. When temperature returns to normal, the
protectors reset automatically.
■
Flowswitch
The unit is protected by a flowswitch (S8L).
When the waterflow becomes lower than the minimum allowed
waterflow, the flowswitch shuts down the unit. When the
waterflow becomes normal, the protection resets automatically
but the controller still needs to be reset manually.
■
Discharge thermal protectors
The unit is equipped with discharge thermal protectors (S*T).
The protectors are activated when the temperature of the
refrigerant leaving the compressor becomes too high. When the
temperature returns to normal the protector resets automatically
and the controller needs to be reset manually.
■
Freeze-up protection
The freeze-up protection prevents the water in the evaporator
from freezing during operation. When the outlet water
temperature is too low, the controller shuts down the cicuit.
When the outlet water temperature returns to normal, the
controller needs to be reset manually.
When freeze-up protection occurs several times in a certain
period, the freeze-up alarm will be activated and the unit will be
shut down. The cause of freezing up should be investigated and
after outlet water temperature has risen enough, the alarm
indicator on the controller needs to be reset manually.
■
Low pressure safety
When the suction pressure of a circuit is too low, the circuit
controller shuts down the circuit. When the pressure returns to
normal, the safety device can be reset on the controller.
■
Pressure relief safety valve
The safety valve is activated when the pressure in the refrigerant
circuit becomes too high. If this occurs, shut down the unit and
contact your local dealer.
■
High pressure switch
Each circuit is protected by two high pressure switches (S*PH)
which measure the condenser pressure (pressure at the outlet
of the compressor). They are installed in the compressor
housing of the circuit. When the pressure becomes too high, the
pressure switches are activated and the circuit stops.
The switches are factory-set and may not be adjusted. When
activated, they must be reset by means of a screwdriver. The
controller still needs to be reset.
■
Reverse phase protector
The reverse phase protectors (R*P) prevent the screw
compressors from running in the wrong direction. If the
compressors do not start, two phases of the power supply must
be inverted.
Internal wiring - Parts table
Refer to the internal wiring diagram supplied with the unit. The
abbreviations used are listed below:
A1,A2..........** ....... Current transfo/A-meter
A1P........................ PCB controller
A11P...................... Expansion bord controller
B1P,B4P................. Low pressure transmitter for circuit 1, circuit 2
B2P,B5P................. High pressure transmitter for circuit 1, circuit 2
C1~C6 ................... Capacitor
E1HC,E2HC .......... Crankcase heater compressor circuit 1, circuit 2
E3H,E4H................ Evaporator heater circuit 1, circuit 2
F1U~F3U ... #.........Main fuses
F4U,F5U .... #.........Fuses for evaporator heater
F6B ........................Fuse for primary of TR1
F7B ........................Fuse for secondary of TR1
F8U ........................Surge proof fuse for A1P
F9B ........................Fuse for secondary of TR2
F12B,F14B.............Fuse for fanmotors
H1P............ * .........Indication lamp general operation
H2P............ * .........Indication lamp alarm
H3P............ * .........Indication lamp operation compressor
H5P............ * .........Changeable output
J1 ...........................Power supply
J2,J3,J6,J20...........Analog input
J4 ...........................Analog output
J5,J7,J8,J19...........Digital input
J11 .........................RS485 connection
J12~J18 .................Digital output
K1M,K4M ...............Linecontactor circuit 1, circuit 2
K2M,K5M ...............Deltacontactor circuit 1, circuit 2
K3M,K6M ...............Starcontactor circuit 1, circuit 2
K7F~K9F................Fancontactor
K17S,K18S ............Overcurrent relay circuit 1, circuit 2
K1A,K4A ................Auxiliary relay for safeties circuit 1, circuit 2
K2A,K5A ................Auxiliary relay compressor thermal protector
circuit 1, circuit 2
K3A,K6A ................Auxiliary relay for discharge thermal protector
circuit 1, circuit 2
K7A,K8A ................Auxiliary relay for safety of high pressure
circuit 1, circuit 2
L1~L3.....................Main supply terminals
M11F-M18F ...........Fan motors
M1C,M2C...............Compressor motor circuit 1, circuit 2
M1S,M2S ...............Stepless capacity control for compressor
circuit 1, circuit 2
PE ..........................Main earth terminal
Q11F-Q18F............Thermal protectors fan motors
Q1M,Q2M ..............Thermal protector compressor motor circuit 1,
circuit 2
R1,R2.....................Auxiliary resistence for feedback (R1F)
R1F,R2F.................Feedback resistance circuit 1, circuit 2
R1P,R2P.................Reverse phase protector circuit 1, circuit 2
R3T ........................Sensor for evaporator inlet water temperature
R4T,R6T.................Sensor for outlet water temperature circuit 1,
circuit 2
R5T ........................Sensor for ambient temperature
R8T ........................Sensor for evaporator outlet water temperature in
a DICN system
S1PH,S2PH ...........High pressure switch circuit 1, circuit 2
S3T,S4T .................Discharge thermal protector circuit 1, circuit 2
S5E ........................Emergency stop push button
S6S ............ * .........Changeable switch for remote function
(e.g. remote start/stop)
S8L,S10L ...............Flowswitch circuit 1, circuit 2
S9L............. #.........Contact that closes if the pump is working
S10S,S11L. * .........Changeable switch for remote function
(e.g. dual setpoint)
