ESIE07-05 Maintenance
Part 5 – Maintenance 5–9
3
5
1
5
1.5 Preventive Maintenance Schedule
Overview
Operation
Ref. No.
TYPE OF OPERATION
SCHEDULE
Weekly Monthly
Six-
Monthly
Yearly
1 Reading and recording of suction pressure x
2 Reading and recording of discharge
pressure
x
3 Reading and recording of supply voltage x
4 Reading and recording of current intensity x
5 Check refrigerant charge and possible
moisture in the circuit refrigerant through the
liquid sight glass
x
6 Check the suction temperature and the
superheating
x
7 Check setting and operation of safety
devices
x
8 Check setting and proper operation of
control devices
x
9 Inspect the condenser for possible scaling
or studging
x
