The Digital Controller ESIE07-05
2–16 Part 2 – Functional Description
3
1
2
4
5
Compressor 2
COMPRESSOR 2
Connector Pin Type Futher information
J1 G/G0 powersupply power for controller
J2 B3 analog input current limit or demand limit
GND GND
+VDC power
J3 B4/BC4 analog input oil discharge PT1000 sensor
B5/BC5 analog input condensor entering water sensor
J4 VG/VGO powersupply
Y1/VGO analog input analog output 0-10 VDC
J5 ID1 digital input on-off compressor switch
ID4 digital input discharge thermal protector
ID5 digital input Low pressure switch
IDC1 powersupply
J6 B6/+VDC
(J2)/GND
analog input compressor load transducer
B7/+VDC
(J2)
analog input high pressure transducer
B8/+VDC
(J2)
analog input oil pressure transducer
GND GND
J7 ID10 digital input compressor contactors
ID11 digital input auxiliary relay
ID12 digital input motor thermal protection/thermal relay
(optional)
IDC9 powersupply
J11 RX/TX- pLAN pLAN
RX/TX+ pLAN pLAN
J12 N02 digital output line contact relay
C1 digital output capacitor
J13 C4 digital output capacitor
N06 digital output loading solenoid valve
J14 C7 digital output capacitor
N07 digital output unloading solenoid valve
J16 C9 digital output capacitor
N09 digital output liquid injection solenoid valve
