The Digital Controller ESIE07-05
2–44 Part 2 – Functional Description
3
1
2
4
5
1.5.10 Alarm List
Introduction The table below shows the list of the possible alarms with the identifier number, the cause and the
reset type (A = auto, M = manual).
Alarm table - Chiller
Code Alarm description
Compressor
off
Fan off
Pump
off
System
off
Reset
(auto/man)
Delay Enabling
AL01 Severe alarm * * * * man no enabling both on master
and slave
AL02 Antifreeze alarm * * * * man or auto
(default is
“manual”)
no resetting mode can be set
by user
AL03 Evaporator pump thermal * * * * man no
AL04 Condenser pump thermal * * * * man no
AL05 Evaporator flow control * * * man selectable enabling both on master
and slave
AL06 Condenser flow control * * * man selectable
AL10 Low-pressure pressure
switch 1
*Circuit 1 man selectable
AL11 Low-pressure pressure
switch 2
*Circuit 2 man selectable
AL12 High-pressure pressure
switch 1
*Circuit 1 man no
AL13 High-pressure pressure
switch 2
*Circuit 2 man no
AL14 Oil-differential pressure
switch 1
*Circuit 1 man selectable
AL15 Oil-differential pressure
switch 2
*Circuit 2 man selectable
AL16 Compressor 1 thermal *Comp 1 man no
AL17 Compressor 2 thermal *Comp 2 man no
AL20 Fan 1 thermal * man no
AL21 Fan 2 thermal * man no
AL22 Fan 3 thermal * man no
AL23 High press. transducer 1 *Circuit 1 * man no
AL24 High press. transducer 2 *Circuit 2 * man no
AL30 Damaged probe B1 * * * * auto 60 sec
AL31 Damaged probe B2 * * * * auto 60 sec
AL32 Damaged probe B3 auto 60 sec
AL33 Damaged probe B4 auto 60 sec
AL34 Damaged probe B5 auto 60 sec
AL35 Damaged probe B6 auto 60 sec
AL36 Damaged probe B7 auto 60 sec
AL37 Damaged probe B8 auto 60 sec
AL40 Pump maintenance man
AL41 Compressor 1 maintenance man
AL42 Compressor 2 maintenance man 30 sec
AL50 Offline unit 1 auto 30 sec
AL51 Offline unit 2 auto
AL54 Evaporator fan thermal man
AL55 Damaged 32k clock card man
ESIE07-05.book Page 44 Friday, December 21, 2007 3:21 PM
