Functional Control ESIE07-05
2–52 Part 2 – Functional Description
3
1
2
4
5
Loading and
unloading zones
The graph below shows the different loading and unloading zones.
Settings Do not change:
■ Max pull down : 0.7° / min
■ Dead band : 0.2°C
■ Reload ∆T : 0.7°C
■ Interstage : 210 s
18a (T in load
band)
Load up to 75% Stop Off Off
18b (T not in load
band)
Fixed at 50% Stop Off Off
19 Unload up to 25% Off Off Off
20 If T is approaching SetP – Waiting
21 If (SetP – T) < Shutdown DT & Cooling
or (T – SetP) < Shutdown DT & Heating
Waiting
22 Stop Off Off Off
23 Off Off Off Off
Step n. Leader Comp. Lag 1 Comp. Lag 2 Comp. Lag 3 Comp.
loading
band
unloading
band
dead band
0.2 ∞C
Regulation band : 3∞C
5.3 5.5 6.3 7∞
7.7
8.5 9.7
123
4a4b
loading
band
unloading
band
dead band
0.2 ∞C
Regulation band : 3∞C
5.3 5.5 6.3 7∞
7.7
8.5 9.7
123
4a4b
ESIE07-05.book Page 52 Friday, December 21, 2007 3:21 PM
