GLS Series Datasheet v1.0

www.grinn-global.com 7

17 SNVS_TAMPER9 Input R6 Multifunction pin.

18 SNVS_TAMPER8 Input N9 Multifunction pin.

21 JTAG_TCK Input M14 JTAG test clock input.

22 JTAG_TMS Input P14 JTAG test mode select.

23 JTAG_TDI Input N16 JTAG test data input.

24 JTAG_TDO Output N15 JTAG test data output.

25 JTAG_TRSTn Input N14 JTAG test reset.

26 JTAG_MOD Input P15 JTAG mode

28 VCC_GPIO Supply Input J13 Supply GPIO port

29 GPIO9 IO M15 Multifunction pin.

30 GPIO8 IO N17 Multifunction pin.

31 GPIO7 IO L16 Multifunction pin.

32 GPIO6 IO K17 Multifunction pin.

33 GPIO5 IO M17 Multifunction pin.

34 GPIO4 IO M16 Multifunction pin.

35 GPIO3 IO L17 Multifunction pin.

36 GPIO2 IO L14 Multifunction pin.

37 GPIO1 IO L15 Multifunction pin.

38 GPIO0 IO K13 Multifunction pin.

40 VCC_UART Supply Input H13 Supply UART port

42 3V3_SNVS Supply Input P12

3V3_SNVS supply must be

turned on before any other

power supply

43 UART1_TX_DATA IO K14 Multifunction pin.

44 UART1_RTSn IO J14 Multifunction pin.

45 UART1_RX_DATA IO K16 Multifunction pin.

46 UART1_CTSn IO K15 Multifunction pin.

49 UART2_TX_DATA IO J17 Multifunction pin.

50 UART2_RTSn IO H14 Multifunction pin.

51 UART2_RX_DATA IO J16 Multifunction pin.

52 UART2_CTSn IO J15 Multifunction pin.
