GRINN LITESOM-IMX6UL-E [6/16] Terminal description

GLS Series Datasheet v1.0

www.grinn-global.com 6

3. Terminal Description

3.1. Pin out

Table below shows liteSOM pin assignments. For complete multifunction pins descriptions refer to section 4 in

i.MX 6UltraLite Reference Manual.

Pin NO Name Type i.MX 6UL ball Description

1, 2, 19, 20,

27, 39, 41, 47,

48, 53, 54, 55,

58, 60, 61, 62,

64, 66, 67, 68

71, 72, 73, 75,

77, 78, 84, 86,

88, 90, 95, 96,

105, 111, 112,

114, 123, 124,

133, 134, 143,

144, 149, 151,

154, 156, 159,

160, 169, 172,

174, 179, 180,

185, 188, 190,

192, 194, 196,

198, 200

GND Ground Power ground

187, 189, 191,

1933, 195,

197, 199

3V3 Supply Input +3.3V power supply input.

3 ONOFF IO R8 Power push-button input.

4 PORn Input P8 Reset.

5 BOOT_MODE1 IO U10 Boot configuration.

6 SNVS_TAMPER7 Input N10 Multifunction pin.

7 BOOT_MODE0 IO T10 Boot configuration.

8 PMIC_STBY_REQ Output U9 Multifunction pin.

9 SNVS_TAMPER0 Input R10 Multifunction pin.

10 PMIC_ON_REQ Output T9 Multifunction pin.

11 SNVS_TAMPER2 Input P11 Multifunction pin.

12 SNVS_TAMPER1 Input R9 Multifunction pin.

13 SNVS_TAMPER4 Input P9 Multifunction pin.

14 SNVS_TAMPER5 Input N8 Multifunction pin.

15 SNVS_TAMPER6 Input N11 Multifunction pin.

16 SNVS_TAMPER3 Input P10 Multifunction pin.
