GLS Series Datasheet v1.0
www.grinn-global.com 9
106 NAND_DQS IO E6 Multifunction pin
3
.
107 ENET2_RX_ER IO D16 Multifunction pin.
108 ENET2_RX_DATA0 IO C17 Multifunction pin.
109 ENET2_RX_EN IO B17 Multifunction pin.
110 ENET2_RX_DATA1 IO C16 Multifunction pin.
113 NVCC_LCD Input E13 Supply LCD port
115
LCD_DATA23
BT_CFG4[7]
1
IO B16
Multifunction pin and boot
configuration.
116
LCD_DATA22
BT_CFG4[6]
1
IO A14
Multifunction pin and boot
configuration.
117
LCD_DATA21
BT_CFG4[5]
1
IO B14
Multifunction pin and boot
configuration.
118
LCD_DATA20
BT_CFG4[4]
1
IO C14
Multifunction pin and boot
configuration.
119
LCD_DATA19
BT_CFG4[3]
1
IO D14
Multifunction pin and boot
configuration.
120
LCD_DATA18
BT_CFG4[2]
1
IO A13
Multifunction pin and boot
configuration.
121
LCD_DATA17
BT_CFG4[1]
1
IO B13
Multifunction pin and boot
configuration.
122
LCD_DATA16
BT_CFG4[0]
1
IO C13
Multifunction pin and boot
configuration.
125
LCD_DATA15
BT_CFG2[7]
1
IO D13
Multifunction pin and boot
configuration.
126
LCD_DATA14
BT_CFG2[6]
1
IO A12
Multifunction pin and boot
configuration.
127
LCD_DATA13
BT_CFG2[5]
1
IO B12
Multifunction pin and boot
configuration.
128
LCD_DATA12
BT_CFG2[4]
1
IO C12
Multifunction pin and boot
configuration.
129
LCD_DATA11
BT_CFG2[3]
1
IO D12
Multifunction pin and boot
configuration.
130
LCD_DATA10
BT_CFG2[2]
1
IO E12
Multifunction pin and boot
configuration.
131
LCD_DATA9
BT_CFG2[1]
1
IO A11
Multifunction pin and boot
configuration.
132
LCD_DATA8
BT_CFG2[0]
1
IO B11
Multifunction pin and boot
configuration.
135
LCD_DATA7
BT_CFG1[7]
1
IO D11
Multifunction pin and boot
configuration.
136
LCD_DATA6
BT_CFG1[6]
1
IO A10
Multifunction pin and boot
configuration.
137
LCD_DATA5
BT_CFG1[5]
1
IO B10
Multifunction pin and boot
configuration.
138
LCD_DATA4
BT_CFG1[4]
1
IO C10
Multifunction pin and boot
configuration.
139
LCD_DATA3
BT_CFG1[3]
1
IO D10
Multifunction pin and boot
configuration.
140
LCD_DATA2
BT_CFG1[2]
1
IO E10
Multifunction pin and boot
configuration.
141
LCD_DATA1
BT_CFG1[1]
1
IO A9
Multifunction pin and boot
configuration.
142
LCD_DATA0
BT_CFG1[0]
1
IO B9
Multifunction pin and boot
configuration.
