ACD-23SW ELECTRICAL SPECIFICATIONS
www.beha-amprobe.com
For detailed specifications and ordering info go to www.beha-amprobe.com Pub ID: 13102-eng
©2014 Beha-Amprobe. All rights reserved.
Beha-Amprobe®
In den Engematten 14,
79286 Glottertal, Germany
Tlf.: +49 (0) 7684 8009 - 0
Resistance
Ranges 200 Ω, 2 kΩ, 20 kΩ, 200 kΩ, 2 MΩ, 20 MΩ
Resolution 0.1 Ω
Accuracy
200 Ω ±(0.5 % rdg+4 dgts)
2 kΩ to 200 kΩ ±(0.3 %rdg+2 dgts)
2 MΩ ±(1.0 % rdg+4 dgts)
20 MΩ ±(2.0 %rdg+4 dgts
OL Protection 1500 V dc/1000 V ac rms
Open Circuit Voltage
200 Ω range 3.0 V dc typical
all other ranges 0.3 V dc typical.
Diode/Continuity Test
Test Current 1m A dc typical
Test/Open Circuit Voltage 3.0 V dc Typical
Diode Accuracy ±(1.5 % rdg+2 dgts)
Continuity Audible Threshold <50 Ω ± 25 Ω
Response Time <100 msec
OL Protection 1500 V dc/1000 V ac rms
For complete specifications please download the product datasheet and the users manual on www.beha-amprobe.com.
