3.3. PC Link

The meter has serial data transmission function. It can be connected with PC by USB interface, so the

measured data can be recorded, analyzed, processed and printed by PC. Before using this function, you

need to install the PC-Link software and USB driver in your PC.

1.Touch the key 6, the symbol “ ”will be displayed on the LCD.

2. Touch the key 5, the meter enter PC-Link mode. The symbol “LINK” will appear on the LCD, and the

serial data output function is active.

3. Touch the key 5 again to exit.

* Only exist at Model D

PC-LINK SOFT OPERATING MANUAL

Please check the software manual for more information.

4. TECHNICAL SPECIFICATIONS

4.1. General specifications

Environment conditions:

1000V CAT III and 600V CAT IV

Pollution degree: 2

Altitude < 2000m

Operating temperature: 0~40℃, 32°F~122°F(<80% RH, <10℃ non-condensing)

Storage temperature: -10~60 ℃, 14°F~140°F(<70% RH, battery removed)

Temperature Coefficient: 0.1x(specified accuracy) / ℃ (<18℃ or >28℃)

MAX. Voltage between terminals and earth ground: 1000V AC rms or 1000V DC.

Fuse Protection: µA and mA: F 0.63A/1000V Ø10.3x38; A: F 10A/1000V Ø10.3x38.

Sample Rate: 3 times/sec for digital data.

Display: 3 5/6 digits LCD display. Automatic indication of functions and symbols.

Range selection: automatic and manual.

Over Range indication: LCD will display ”OL”.

Low battery indication: The ” ” is displayed when the battery is under the proper operation range.

Polarity indication: ”-” displayed automatically.

Power source: 3V

Battery type: AA*2, or chargeable Lithium battery 3.7V (not included).

Dimensions: 190(L)x90(W)x40(H) mm.

Weight: 500g. Approx. (battery included).
