• Do not touch the charging connector when the test lead is connected.

Caution!

To avoid possible damage to meter or to equipment under test:

• Disconnect the power and discharge all high-voltage capacitors before testing resistance or continuity.

• Use the proper jacks, function, and range for the measurement or sourcing application.

International Electrical Symbols

AC Current

DC Current

AC or DC

of Impulse Withstand Voltage protection provided. Typical locations include: Plug and the connecting

electric

equipments, home appliance, convenient, tools, domestic plug, plugs 10m distant from type 3 circuit or

20m distant from type 4 circuit.

3. Measuring Electrical Parameters

The proper sequence for taking measurements follows:

1. Plug the test lead into the appropriate jacks

2. Set the rotary function switch to the desired function

3. Touch the probes to the test points

4. View the results on the LCD display
