Ariston ALD 128 D [27/32] Technical characteristics

Margherita - Iinstructions for installation and use

ARGHERITA

Model

ALD 128 D

Dimensions

width 59,5 cm

height 85 cm

depth 53,5 cm

Capacity

from 1 to 5 kg for the wash programme; from 1 to 4 kg for the drying

programme

Electrical

connections

voltage 220/230 Volt 50 Hz

maximum absorbed power 1850 W

Water

connections

maximum pressure 1 MPa (10 bar)

minimum pressure 0,05 MPa (0,5 bar)

drum capacity 46 litre

Spinning speed

up to 1200 rpm

Control programs

in compliance

with IEC

regulation 456

wash:

programme 3; temperature 60°C; rinse level ;

wash intensity ; carried out with 5 kg load;

drying

: run w ith a 2.5 kg load, setting the type of drying .

This appliance conforms with the following E.E.C. directives:

- 73/23/EEC of 19/02/73 (Low Voltage) and subsequent modifications

- 89/336/EEC of 03/05/89 (Electromagnetic Compatibility) and

subsequent modifications

The washer-dryer

does not drain or spin.

Does the selected

programme incorporates

water draining? Some

programmes stop at the end of

the wash cycles and draining

will have to be selected

manually.

Is the Easy iron" function

-where provided - enabled?

Complete the programme by

pressing the Select button.

Is the drain pump clogged?

To check it, turn off the water

supply, unplug the washer-

dryer and follow the

instructions on page 26, or call

for technical assistance.

Is the drain hose kinked?

The tract of the drain hose

must be as straight as possible.

Make sure the drain hose is not

squashed or kinked.

Is the washer-dryers drain

duct clogged? Is there an

extension of the drain hose? If

so, is it positioned incorrectly,

blocking the water flow?

Excessive vibration

during the spin cycle.

Have all transit screws been

removed durind instal-

lation? See the following

page on installation

procedures.

Has the washer-dryer been

levelled correctly? The

levelling of the appliance

should be checked

periodically. Adjust the feet

and check them with a level.

Is there space between the

machine and adjacent units?

If it is not a built-in model, the

washer-dryer will oscillate a bit

during the spin cycle. A few cm

of space should therefore be left

around it.

The washer-dryer

leaks.

Is the metal ring of the inlet

hose properly attached? Turn

off the water supply, unplug

the appliance and try

tightening its attachment

without forcing it.

Is the detergent dispenser

obstructed? Remove and

wash it under tap water.

Is the drain hose well

attached? Turn off the water

supply, unplug the appliance

and try tightening its

attachment.

Too much foam.

Is the detergent appropriate

for machine washing? Check

whether the definition on its

label reads for machine wash

or hand and machine wash,

or any other similar wording.

Is the correct amount being

used? An excessive amount of

detergent, besides producing

too much foam, does not

guarantee a more effective

wash, and causes scaling in the

internal parts of the appliance.

The washer-dryer

does not dry.

Check whether:

the plug has been correctly

inserted into the socket; there

is electricity in your home; the

appliance door has been shut

properly; a delayed start (if

available) has not been selected;

the drying mode has been

selected.

The washer-dryer

doesn't dry properly.

Check whether:

the end of the drain hose is

underwater; the drain pump is

obstructed; the advice given on

the maximum loads has been

taken; the water tap has been

turned on.

If, despite all checks, the washer-

dryer fails to function and the

problem persists, call your

nearest authorised Customer

Service Centre, providing the

following information:

- the nature of malfunction

- the model type no. (Mod. ....)

- the serial number (S/N ....)

This information can be found on

the data plate situated at the back

of the washer-dryer.

Technical characteristics

Always get

assistance from

authorised

technicians and

always insist on

original spare

parts.
