Ariston ALD 128 D [28/32] When margherita arrives

ARGHERITA

Margherita - Instructions for installation and use

When Margherita

arrives

Installation and removal

Whether new or just transported to a new house,

installation is extremely important for the correct

functioning of your washer-dryer.

The hook to be used in case the drain

hose ends at a height below 60 cm.

If the drains hose empties into a

tub or sink then fit the plastic

guide and secure it to the tap.

The guide for draining into tubs and

sinks.

The end of the drain hose must

be positioned so that it cannot

become submerged.

Extensions are unadvisable. In

case of absolute need, the

extension must have the same

diameter as the original hose and

must not exceed 150 cm. In case

of wall draining pipes, their

efficiency must be checked by a

qualified technician. If the

dwelling is on one of the upper

floors of a building, there may be

drain trap problems causing the

washer-dryer to load and unload

water continuously.

In order to avoid such an

inconvenience, special anti-drain

trap valves are available in shops.

Electric connection

Before connecting the appliance

to the electric socket, be sure

that:

1) the electric socket is able to

sustain the appliances

maximum power load

indicated on the data plate

and in compliance with the

law;

2) the supply voltage is included

within the values indicated

on the data plate;

3) the socket is compatible with

the appliances plug. If not,

do not use adapters, but

replace either the socket or

the plug;

4) electric household appliances

must be equipped with an

earthing system.

After removing the appliance

from its packaging, check that it

is intact. If in doubt, contact a

qualified technician immediately.

The inside of the machine is

supported, for transportation, by

four screws on the back panel.

Before using the washer-dryer,

remove the screws, remove the

spacers together with the rubber

tubes attached to them (keeping

all the parts) and use the plastic

plugs provided to fill in the holes.

Important: Use the cap (provided)

to close the 3 holes which housed

the stop pin, situated in the right-

hand part of the lower back of the

washer-dryer.

Levelling

The washer-dryer must be

levelled appropriatey in order to

guarantee its correct functioning.

To level the appliance, the front

feet must be adjusted; the angle

of inclination, measured

according to the worktop, must

not exceed 2°. When placed on

carpet, make sure the ventilation

is not reduced.

The front feet are adjustable.

Connection to the water

mains

Water pressure must range within

the values indicated on the data

plate on the rear of your washer-

dryer. If the water pipes are new

or left unused, then before

connecting the machine run the

water until clear to remove

debris. Connect the inlet hose to

a cold water tap having a ¾  BSP

thread. Ensure that the rubber

sealing washers are fitted at each

end of the inlet hose, with the fitter

washer at the tap end.

The rubber gasket .

Connect the inlet hose to the

threaded connector on the

machine rear.

Water pipe inlet at the top right.

Connecting the drain

hose

There are two hooks (right or

left) on the rear of your washer-

dryer to which the drain hose is

to be fixed. Insert the other end

in a stand pipe or place it on the

edge of a sink or tub avoiding

excessive kinks and bending. It

should be placed at a height

ranging from 60 to 100 cm. If it

is necessary to fix the end of the

hose at a height below 60 cm

from the ground, it must be fixed

in the appropriate hook placed

on the upper part of the back

panel.

Warning!

The company denies

all liability if and

when these norms are

not respected.

Plastic bags,

expanded styrofoam,

nails and other

packaging parts are

not childrens toys,

and are potentially

dangerous.

Retain the transit screws,

spacers and washers.

Should you move house

then these should be

replaced to support the

inside of the machine to

prevent damage when

transporting the

machine.
