Ariston ALD 128 D [30/32] Your safety and that of your family

ARGHERITA

Margherita - Instructions for installation and use

Your safety and that of

your family

Important for the safe use of your Margherita

Margherita has been built in compliance with

the strictest international safety regulations.

To protect you and all your family.

Read these instructions and all

the information in this manual

carefully: they are an

important source, not only of

numerous useful tips, but also

of vital information on safety,

use and maintenance.

1. Margherita should not be

installed in an outdoor

environment, not even

when a roof shelters the

area, because it may be

very dangerous to leave it

exposed to rain and

thunderstorms.

2. It must only be used by

adults and exclusively for

washing clothes following

the instructions provided in

this manual.

3. Should it have to be moved,

proceed with the help of

two or three people and

handle it with the utmost

care. Never try to do this

alone, because the

appliance is very heavy.

4. Before loading the washer-

dryer, make sure the

drum is empty.

5. Never touch the washer-

dryer when barefoot or

with wet or damp hands

or feet.

6. Never use extensions or

multiple plugs, which are

particularly dangerous in

humid environments. The

power supply cable must

never be bent or

dangerously compressed.

7. Never open the detergent

dispenser while the

appliance is functioning;

do not use hand wash

detergent because the

abundance of foam could

damage its internal parts.

How to change the power supply cable

The Margherita power

supply cable is special

and can be purchased

exclusively from

authorised Technical

Service Centres.

To replace the cable:

1. Make sure that Marghe-

rita is switched off and

unplugged.

2. Remove the covering lid by

unscrewing the two screws

I, and then pull it towards

you [fig. 3].

3. Disconnect the wires from

the radio interference

suppressor F [fig. 4] noting as

to their position (Blue=N wire;

Brown=L wire) leaving the

earth wire until last

N.B.: letters L, N and the

symbol

are indicated on

the radio interference

suppressor.

4. Remove the upper part of

the cable slightly from the

back panel of the appliance,

pull the power supply cable

upwards and take it out

[fig. 5].

To connect the new power

supply cable, reverse the pro-

cedure.

To put the covering lid back

on, rest it on the washer-

dryer [fig. 6] and let it slide

forwards until the hooks

situated on the front slide

into the special slots formed

into the control panel and

tighten the screws back on.

Fig. 3

Fig. 4 Fig. 5 Fig. 6

8. Never pull on the supply

cable or the washer-dryer

to disconnect it from the

wall socket: it is extremely

dangerous.

9. While the appliance is

functioning, do not touch

the drain water as it

could reach very high

temperatures. The

appliance door, during

wash cycles, tends to

become hot; ensure that

children do no touch it.

Never force the washer-

dryer door because this

could damage the safety

lock which prevents

accidental opening when

the nachine is working.

Allow a few minutes at the

end of the program for the

lock to release.

10. In case of malfunctio-

ning, first close the

water tap and unplug the

appliance from the wall

socket; do not under any

circumstances touch

internal parts in order to

attempt repairs.

I only want an

authorised specialised

technician with original

Ariston spare parts!
