2 3
ACTDUALCHANNELWIRELESSRECEIVER ACTDUALCHANNELWIRELESSRECEIVER
2.PARTSNAMEANDFUNCTIONS
FrontPanel：
RearPanel：
(Fig.1)
(Fig.2)
(1)FrontAntennaAInputConnector:Allowsanoptionalrear-to-front
Antennakitforfrontantennaplacement.
(2)PowerSwitch&Indicator:Whenswitchisturnedon,redindicator
illuminatestodenotenormalpowerstatus.
(3)ReceiverPanelA:ColorLCDPanelA.
(4)ReceiverPanelB:ColorLCDPanelB.
(5)FrontAntennaBInputConnector:Allowsanoptionalrear-to-front
Antennakitforfrontantennaplacement.
(6)AntennaBinputConnector:AntennaBconnectorcanbeinstalledwith
antennadirectlyandprovidespowerforantennabooster.
(7)(10)BalancedAudioOutputJack:WithCannon/XLRtypeconnector
providesbalancedaudiooutputsignalthatmatchescapsulesensitivity.
(8)UnbalancedAudioMixedOutputJack:With1/4PhoneJack
providesthemixedunbalancedaudiooutputsignalfromthisjacktothe
amplifier.
(9)UnbalancedLevelSwitch:"MIC"selectionisfor"Microphone-level"
output."LINE"selectionisfor"Line-out"leveloutput.
(11)ComputerNetworkInterfaceConnector: Networksockettoconnectto
thecomputerizedsystem-monitoringprogram.
(12)ACInputJack:Toconnect85~265VoltsACpower.
(13)AntennaAinputConnector:AntennaAconnectorcanbeinstalledwith
antennadirectlyandprovidespowerforantennabooster.
(14)RackmountBracket:ToinstallthereceiverintoanEIA19-inchstandard
rackcase.
λ
13 14
3:COLD
-
1:GND
+
2:HOT
3
21
MADEINTAIWAN
LEVELMIXOUTBALANCEDOUTB ANTENNAA
AC100V~240V
MIC LINE
+8VDCBIAS +8VDCBIAS
ANTENNAB
REMOTE
INOUT
BALANCEDOUTA
7 8 9 10
11
6 12
2 3 4
ACT-707D WirelessReceiver
ON
POWER
A B
1 5
RF AF
MHz
G/CH
VOL
FREQ SQ
REMONAME
BATANT
BA
RF AF
MHz
G/CH
VOL
FREQ SQ
REMONAME
BATANT
BA
ACT
MENU
GROUP
SCAN
ACT
MENU
GROUP
SCAN
