12 13
ACTDUALCHANNELWIRELESSRECEIVER ACTDUALCHANNELWIRELESSRECEIVER
ACT
ACT EXIT
OperationofACTFeature:
A.OperatingProcedures.
B.HowtoOperate?
a.AtLCDpaneldisplays"Group"and"Channel"modekeystroke"ACT"
button.ACTmodeisactivatedwhen"ACT"wordappearsonthe
LCDpanel.
b.Movemicrophonetowardtoreceiverwithinthedistancearoundcm,
andfacethe"ACT"markedsideonthemicrophonetothe"ACT"
buttononthepanelofreceiver,seebelowfigure.
c.ACTfunctionwillreleaseautomaticallyoncethetransmitterchannelis
lockedon.Simultaneously,"Group"and"Channel"modewillbe
backshowingontheLCDpanel.Bothtransmitterandreceiver
shouldshowthesame"Group"and"Channel".Thisindicates
transmitterfrequencyset-upissuccessful.Ifunsuccessful,repeatstep
"A".
30
ACT
ACT
MENU
GROUP
SCAN
(6)REMO:Indicatesorsetupthereceiveraddressandstatusofremotecontrolling.
A.OperatingProcedures.
B.HowtoOperate?
a.ACT-BUSinterfaceisadaptedforMIPROWirelessReceiverModule.WithMIPRO
InterfaceConverterandMonitoringSoftware,upto64receivermodulescanbe
remote-controlledsimultaneouslyviaaPC.
b.Addresscanbesetwithintherangeof01-64.Underremotecontrolmode,each
receivermoduleMUSThasitsownaddress.If2differentreceivermodulesare
usingthesameaddress,itwillcauseconflictionandresultinmonitoringerror.
However,ifnotunderremotecontrolmode,operationwillremainnormalevenif2
differentreceivermodulesareusingthesameaddress.
c.Inremotecontrolmode,"ON"willbeshownintheLCDdisplaypanelandthe
numbernexttothemessageistheaddressofthereceivermodule.However,
"OFF"willbeshownisthesystemisnotremotelylinkedtothePC.
d.Push"UP"or"DOWN"buttontochangereceiveraddressandverifybypushingthe
"MENU"button.
save
REMO
MENU
64
EXITMENU
DOWN UP
ACT
MENU
GROUP
SCAN
