Fluke FLK-8845A/SU [89/93] Rs 232 port connections

C-1

Appendix C

RS-232 Port Connections

Introduction

Table C-1 lists the pins and related signals available through the RS-232 port.

Table C-1. RS-232 Pin to Signal List

Pin Name Usage

1 DCD Not used

2 RX Receive data

3 TX Transmit data

4 DTR Not used

5 GND Signal ground

6 DSR Not used

7 RTS Request to send

8 CTS Clear to send

9 RI Not used

The Meter’s RS-232 control lines can be rewired to an alternate pairing instead of the

RTS/CTS control pair. This alteration should be done by a trained technician at Fluke

service center. Opening the cover of the Meter to make this alteration may void the

Meter’s warranty.
