Gigabyte GA-AX370-Gaming (rev. 1.x) [10/40] Ps 2 keyboard mouse port

1-5 Installing an Expansion Card

Readthefollowingguidelinesbeforeyoubegintoinstallanexpansioncard:

• Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

• Always turn off the computer and unplug the power cord from the power outlet before installing an

expansion card to prevent hardware damage.

1-6 Back Panel Connectors

PS/2 Keyboard/Mouse Port

Use this port to connect a PS/2 mouse or keyboard.

USB 3.1 Gen 1 Port

TheUSB3.1Gen1portsupportstheUSB3.1Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

HDMI Port

TheHDMIportisHDCPcompliantandsupportsDolbyTrueHDandDTSHD

MasterAudioformats.It alsosupports upto 192KHz/24bit 8-channelLPCM

audiooutput.YoucanusethisporttoconnectyourHDMI-supportedmonitor.Themaximumsupported

resolutionis 4096x2160@24Hz,but theactualresolutions supportedare dependent onthe monitor

being used.

AfterinstallingtheHDMIdevice,makesuretosetthedefaultsoundplaybackdevicetoHDMI.(The

itemnamemaydifferdependingonyouroperatingsystem.)

USB 3.1 Gen 2 Type-A Port (Red)

TheUSB3.1Gen2Type-AportsupportstheUSB3.1Gen2specicationandiscompatibletotheUSB

3.1Gen1andUSB2.0specication.UsethisportforUSBdevices.

DuetoCPUlimitations,readthefollowingguidelinesbeforeinstallingthememoryinDualChannelmode.

1. DualChannelmodecannotbeenabledifonlyonememorymoduleisinstalled.

2. WhenenablingDualChannelmodewithtwoorfourmemorymodules,itisrecommendedthatmemory

of the same capacity, brand, speed, and chips be used. For optimum performance, when enabling

DualChannelmodewithtwomemorymodules,werecommendthatyouinstallthemintheDDR4_1

andDDR4_2sockets.

DualChannelMemoryCongurationsTable:

DDR4_4 DDR4_2 DDR4_3 DDR4_1

2 Modules

- - DS/SS - - DS/SS

DS/SS - - DS/SS - -

4 Modules DS/SS DS/SS DS/SS DS/SS

(SS=Single-Sided,DS=Double-Sided,"--"=NoMemory)

- 10 -
