![Gigabyte GA-AX370-Gaming (rev. 1.x) [4/40] Ga ax370 gaming motherboard layout](/img/pdf.png)
Gigabyte GA-AX370-Gaming (rev. 1.x) [4/40] Ga ax370 gaming motherboard layout
![Gigabyte GA-AX370-Gaming (rev. 1.x) [4/40] Ga ax370 gaming motherboard layout](/views2/1666525/page4/bg4.png)
- 4 -
GA-AX370-Gaming Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-AX370-Gaming motherboard 5 Quick Installation Guide
5 Motherboard driver disk 5 Four SATA cables
5 User's Manual 5 I/O Shield
Socket AM4
KB_MS_USB30
CPU_FAN
SYS_FAN1
ATX
F_USB30_2
AUDIO
DDR4_4
DDR4_2
BAT
ATX_12V
CODEC
CLR_CMOS
M_BIOS
Realtek
®
GbE LAN
PCIEX16
PCIEX1_2
iTE
®
Super I/O
GA-AX370-Gaming
F_PANEL
F_AUDIO
SPDIF_O
PCIEX1_1
SATA3
USB30_LAN
HDMI
0 2 4 6
1 3 5 7
AMD
X370
F_USB2TPM
R_USB30
B_BIOS
R_USB31
M2F_32G
80 60 42110
DDR4_3
DDR4_1
F_USB30_1
SYS_FAN3_PUMP
PCIEX1_3
PCIEX4
SYS_FAN2
F_USB1COMA
ASMedia
®
USB 3.1 Gen 2
Controller
