Please visit GIGABYTE's website for more software information.

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour

device and then remove it from the motherboard.

• Whenremovingthecable,pullitstraightoutfromtheconnector.Donotrockitsidetosidetoprevent

an electrical short inside the cable connector.

RJ-45 LAN Port

The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following

describesthestatesoftheLANportLEDs.

ActivityLED

Connection/

SpeedLED

LAN Port

ActivityLED:Connection/SpeedLED:

State Description

Orange 1 Gbps data rate

Green 100 Mbps data rate

Off 10 Mbps data rate

State Description

Blinking Datatransmissionorreceivingisoccurring

Off No data transmission or receiving is occurring

Center/Subwoofer Speaker Out (Orange)

Usethisaudiojacktoconnectcenter/subwooferspeakersina5.1/7.1-channelaudioconguration.

Rear Speaker Out (Black)

Thisjackcanbeusedtoconnectrearspeakersina4/5.1/7.1-channelaudioconguration.

Side Speaker Out (Gray)

Usethisaudiojacktoconnectsidespeakersina7.1-channelaudioconguration.

Line In (Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

Line Out (Green)

The line out jack. Use this audio jack for a headphone or 2-channel speaker. This jack can be used to

connectfrontspeakersina4/5.1/7.1-channelaudioconguration.

Mic In (Pink)

The Mic in jack.

- 11 -
