H410M DS2V Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you
obtain. The box contents are subject to change without notice.
Box Contents
5 H410M DS2V motherboard
5 Motherboard driver disc 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS_USB
CPU_FAN
SYS_FAN
LGA1200
ATX
H410M DS2V
F_AUDIO COM
LED_C
AUDIO
BAT
ATX_12V 2X4
Intel
®
H410
U32
CODEC
CLR_CMOS
M_BIOS
VGADVI
USB_LAN
PCIEX16
80 60 42
PCIEX1_1
PCIEX1_2
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1
F_PANEL
SPI_TPM
F_U32
DDR4_2
DDR4_1
M2M_SB
3 2
1 0
SATA3
