1-5 Installing an Expansion Card

Readthefollowingguidelinesbeforeyoubegintoinstallanexpansioncard:

• Make sure the motherboard supports the expansion card. Carefully read the manual that came

with your expansion card.

• Always turn off the computer and unplug the power cord from the power outlet before installing an

expansion card to prevent hardware damage.

1-6 Back Panel Connectors

PS/2 Keyboard and PS/2 Mouse Port

Usetheupperport(green)toconnectaPS/2mouseandthelowerport(purple) toconnect a PS/2

keyboard.

D-Sub Port

TheD-Subportsupportsa15-pinD-Subconnectorandsupportsamaximumresolutionof

1920x1200@60Hz(theactualresolutionssupporteddependonthemonitorbeingused). Connect a

monitorthatsupportsD-Subconnectiontothisport.

HDMI Port

TheHDMIportsupportsHDCP2.2andDolbyTrueHDandDTSHDMaster

Audioformats. Italsosupportsupto192KHz/16bit8-channel LPCMaudio

output.YoucanusethisporttoconnectyourHDMI-supportedmonitor.Themaximumsupported

resolutionis4096x2160@30Hz,but the actual resolutionssupportedaredependentonthe monitor

being used.

DuetoCPUlimitations,readthefollowingguidelinesbeforeinstallingthememoryinDualChannelmode.

1. DualChannelmodecannotbeenabledifonlyonememorymoduleisinstalled.

2. WhenenablingDualChannelmodewithtwomemorymodules,itisrecommendedthatmemoryof

the same capacity, brand, speed, and chips be used.

ThetwoDDR4memorysocketsaredividedintotwochannelsandeachchannelhasonememorysocketas

following:

ChannelA:DDR4_1

ChannelB:DDR4_2

USB 3.1 Gen 1 Port

TheUSB3.1Gen1portsupportstheUSB3.1Gen1specicationandiscompatibletotheUSB2.0

specication.UsethisportforUSBdevices.

AfterinstallingtheHDMIdevice,makesuretosetthedefaultsoundplaybackdevicetoHDMI.(The

itemnamemaydifferdependingonyouroperatingsystem.)
