TECHNICAL SPECIFICATIONS C11 C12 C13 C14
Capacity (1) kW 1078 1125 1188 1267
---
% 8.3 8.3 8.3 8.3
Unit power input (1) kW 296 312 329 347
--- 3.64 3.60 3.61 3.65
---
---
Height mm 2415 2415 2415 2415
Width mm 2135 2135 2135 2135
Length mm 4426 4426 4426 4426
kg 5167 5167 5188 5208
kg 5671 5671 5677 5680
---
l 504 489 472 504
Cooling l/s 51.50 53.75 56.76 60.53
Cooling kPa 46 49 41 51
---
l48484848
No.3333
Cooling dB(A) 100.8 101.2 103 100.4
Cooling dB(A) 80.8 81.2 83 80.4
--- R-134a R-134a R-134a R-134a
kg.5555
No.3333
Piping connections mm 219.1 219.1 219.1 219.1
Liquid connections mm42424242
Gas Discharge connections mm 88.9 88.9 88.9 88.9
Safety devices
Notes (1)
Notes (2)
EWLD~I-SS
Cooling
Type
Ivory White
Unit
Insulation material
Galvanized and painted steel sheet
Minimum capacity
EER (1)
Stepless
Casing
Colour
Cooling
Material
Dimensions
Capacity control
Weight
Unit
Operating Weight
Water heat exchanger
Evaporator
Oil charge
Single Pass Shell&Tube
Water volume
Nominal water flow rate
Nominal Water pressure drop
Type
Sound level
Closed cell
Sound Power (2)
Sound Pressure (2)
Compressor
Type
Semi-hermetic
single screw compressor
High discharge pressure (pressure transducer)
Quantity
Refrigerant circuit
Refrigerant type
Refrigerant charge
N. of circuits
Low oil pressure
High discharge pressure (pressure switch)
Inlet
Outlet
Evaporator water inlet/outlet
Low pressure ratio
Low suction pressure (pressure transducer)
Compressor motor protection
High discharge temperature
Water freeze protection controller
High oil filter pressure drop
Phase monitor
Emergency stop button
Cooling capacity, unit power input in cooling and EER are based on the following conditions: evaporator 12/7°C;
45 °C saturated discharge temperature at the compressor.
The values are according to ISO 3744 and are referred to: evaporator 12/7°C, saturated discharge temperature
45°C, full load operation.
