6
Electrical control panel
Power and control are located in the main panel that is manufactured to ensure protection against all weather conditions.
The electrical panel is IP54 and (when opening the doors) internally protected with Plexiglas panel against possible
accidental contact with electrical components (IP20). The main panel is fitted with a main switch interlocked door.
Power Section
The power section includes compressors fuses and control circuit transformer.
MicroTech III controller
MicroTech III controller is installed as standard; it can be used to modify unit set-points and check control parameters. A
built-in display shows chiller operating status plus temperatures and pressures of water, refrigerant, programmable values,
set-points. A sophisticated software with predictive logic, selects the most energy efficient combination of compressors and
EEXV to keep stable operating conditions to maximise chiller energy efficiency and reliability.
MicroTech III is able to protect critical components based on external signs from its system (such as motor temperatures,
refrigerant gas and oil pressures, correct phase sequence, pressure switches and evaporator). The input coming from the
high pressure switch cuts all digital output from the controller in less than 50ms, this is an additional security for the
equipment.
Fast program cycle (200ms) for a precise monitoring of the system. Floating point calculations supported for increased
accuracy in P/T conversions.
Control section - main features
• Management of the compressor stepless capacity.
• Chiller enabled to work in partial failure condition.
• Full routine operation at condition of:
- high ambient temperature value
- high thermal load
- high evaporator entering water temperature (start-up)
• Display of evaporator entering/leaving water temperatures.
• Display of condensing-evaporating temperatures and pressures, suction and discharge superheat for each circuit.
• Leaving water evaporator temperature regulation. Temperature tolerance = 0,1°C.
• Compressor and evaporator pumps hour counters.
• Display of Status Safety Devices.
• Number of starts and compressor working hours.
• Optimized management of compressor load.
• Re-start in case of power failure (automatic / manual).
• Soft Load (optimized management of the compressor load during the start-up).
• Start at high evaporator water temperature.
• Return Reset (Set Point Reset based on return water temperature).
• Set point Reset (optional).
• Application and system upgrade with commercial SD cards.
• Ethernet port for remote or local servicing using standard web browsers.
• Two different sets of default parameters could be stored for easy restore.
Safety device / logic for each refrigerant circuit
• High pressure (pressure switch).
• High pressure (transducer).
• Low pressure (transducer).
• High compressor discharge temperature.
• High motor winding temperature.
