Insulation Tester
The Tester
7
The Tester
The subsequent sections tell you about the Tester and its operation. The Tester
is shown in Figure 2.
1
2
4
5
6
7
3
ghh16.eps
Item Description Item Description
LCD
IR Port
Safety Shutter
Pushbuttons
AC plug
Built in Handle
Input Terminals
Figure 2. 1550C/1555 Insulation Tester
