Insulation Tester
Specifications
29
Table 3. Accessories
Accessories Part No.
Extended Test Lead Set, 25 feet (7.6 meters) 2032761
Rugged Alligator Clamps 3611951
Soft Case 3592805
Hard Case 3671624
Specifications
General Specifications
Display 75 mm x 105 mm
Power 12 V lead-acid rechargeable battery.
2.6 Ahr
Charger Input (AC) 85 V to 250 V ac, 50/60 Hz, 20 VA
This Class II (double insulated) instrument is
supplied with a Class 1 (grounded) power
cord. The protective earth terminal (ground
pin) is not connected internally. The extra
pin is for added plug retention only.
Dimensions (H x W x L) 170 mm x 242 mm x 330 mm
(6.7 in. x 9.5 in. x 13.0 in.)
Weight 3.6 kg (7.94 lbs.)
Temperature (operating) -20
o
C to 50
o
C (-4
o
F to 122
o
F)
Temperature (storage) -20
o
C to 65
o
C (-4
o
F to 149
o
F)
Relative Humidity 80 % to 31
o
C decreasing linearly to 50 % at
50
o
C
Altitude 2000 m
Enclosure Sealing IP40
Input Overload Protection 1000 V ac
