Insulation Tester
Measurements
25
1
2
GHH04.EPS
Item Description
IR Port
IR Device
Figure 12. IR Port on 1550C/1555 Insulation Tester
Install FlukeView Forms Basic Software
FlukeView Forms Basic software must be installed on your PC to download
stored test data.
To install FlukeView Forms Basic, see the FlukeView Forms Installation
Guide.
To install the infrared adapter, see the USB-IR Cable Installation Guide.
