- 11 -
Hardware Installation
Expansion Slots 2xPCIExpressx16slots,runningatx8(PCIEX8_1~2)
* ThePCIEX8_1slotsharesbandwidthwiththePCIEX16_1slotandthePCIEX8_2
slot with PCIEX16_2. The PCIEX16_1/PCIEX16_2 slot will operate at up to x8 mode
when the PCIEX8_1/PCIEX8_2 is populated.
(AllPCIExpressx16slotsconformtoPCIExpress3.0standard.)
3 x PCI Express x1 slots
(ThePCIExpressx1slotsconformtoPCIExpress2.0standard.)
Multi-Graphics
Technology
Support for 4-Way/3-Way/2-Way AMD CrossFire
™
/NVIDIA
®
SLI
™
technology
Storage Interface
Chipset:
- 1 x SATA Express connector
- 6xSATA6Gb/sconnectors(SATA30~5)
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
(SATAExpressandSATA34/5connectorscanonlybeusedoneatatime.)
2 x Marvell
®
88SE9172 chips:
- 4xSATA6Gb/sconnectors(GSATA36~9)
- Support for RAID 0 and RAID 1
USB
Chipset:
- 4xUSB3.0/2.0ports(2portsonthebackpanel,2portsavailablethrough
theinternalUSBheader)
- 8xUSB2.0/1.1ports(2portsonthebackpanel,6portsavailablethrough
theinternalUSBheaders)
Chipset + Renesas
®
uPD720210 USB 3.0 Hub:
- 4 x USB 3.0/2.0 ports on the back panel
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x PCIe power connector
1 x SATA Express connector
10 x SATA 6Gb/s connectors
1 x CPU fan header
1xwatercoolingfanheader(CPU_OPT)
5 x system fan headers
1 x front panel header
1 x front panel audio header
1 x USB 3.0/2.0 header
3 x USB 2.0/1.1 headers
1 x Clear CMOS jumper
1 x power button
1 x reset button
1 x Clear CMOS button
2 x audio gain control switches
8 x onboard voltage measurement points
2 x BIOS switches
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x optical S/PDIF Out connector
1 x DVI-I port
1 x DisplayPort
1 x HDMI port
