Gigabyte GA-AB350M-DASH (rev. 1.0) [12/40] 7 internal connectors

1-7 Internal Connectors

Readthefollowingguidelinesbeforeconnectingexternaldevices:

• First make sure your devices are compliant with the connectors you wish to connect.

• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power

cord from the power outlet to prevent damage to the devices.

• After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

1) ATX_12V

2) ATX

3) CPU_FAN

4) SYS_FAN1/2

5) ASATA3 0/1

6) SATA3 0/1/2/3

7) M2F_32G

8) F_PANEL

9) F_ AUDIO

10) SPKR

11) F_USB30

12) F_USB1/F_USB2

13) COMA/COMB

14) LPT

15) CLR_CMOS

16) BAT

1410

9 8

1213

- 12 -
