Gigabyte GA-AB350M-DASH (rev. 1.0) [4/40] Box contents
![Gigabyte GA-AB350M-DASH (rev. 1.0) [4/40] Box contents](/views2/1669301/page4/bg4.png)
- 4 -
GA-AB350M-DASH Motherboard Layout
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-AB350M-DASH motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
KB_MS
CPU_FAN
SYS_FAN1
ATX
GA-AB350M-DASH
AUDIO
BAT
ATX_12V
AMD B350
R_USB31
USB30_LAN
R_USB30
CODEC
M_BIOS
BUZZER
DP2
VGA
DP
HDMI
PCIEX16
PCIEX1
PCIEX4
iTE
®
Super I/O
Realtek
®
GbE LAN
F_PANELF_USB30
CLR_CMOS
F_USB1
F_USB2
LPTCOMBCOMA
TPM IC
F_AUDIO
SATA3
ASATA3
0 2
1 3
0 1
426080110
M2F_32G
30
M2_WIFI
Socket AM4
SYS_FAN2
DDR4_4
DDR4_2
DDR4_3
DDR4_1
SPKR
