67/100
OPERATING LIMITS
Minimum water flow
In the following tables are indicated the minimum water flow allowed for each model. For application with Variable
Primary Flow (opt. code 143) refer to the following value for the dimensioning of the bypass line.
In case of variable flow application where the speed of the pump is managed by an external BMS (trough 0- 10V
signal) the change in water flow rate must not be exceed more than 10% of design water flow rate (at standard
conditions) per minute.
The minimum flow indicated correspond to the minimum flow allowed at minimum load for the unit. It is not
intended as minimum flow allowed for unit full load operation.
For minimum flow allowed (maximum deltaT) in full load operation refer to Selection Software. The below values
are referred to pure water (in case of glycol mixture contact factory).
Note: the performances are certified at standard conditions and with the unit operating with the nominal water
flow (corresponding to OAT 35°C; water in/out 12/7°C)
Unit model
water flow [l/s]
Standard Sound
Low Sound
Reduced sound
min
SILVER
EWAH170TZSSB1
EWAH170TZSLB1
EWAH170TZSRB1
4,8
EWAH200TZSSB1
EWAH200TZSLB1
EWAH200TZSRB1
6,9
EWAH240TZSSB1
EWAH240TZSLB1
EWAH240TZSRB1
6,9
EWAH290TZSSB1
EWAH290TZSLB1
EWAH290TZSRB1
8,3
EWAH330TZSSB1
EWAH330TZSLB1
EWAH330TZSRB1
8,3
EWAH390TZSSB2
EWAH390TZSLB2
EWAH390TZSRB2
8,7
EWAH420TZSSB2
EWAH420TZSLB2
EWAH420TZSRB2
8,7
EWAH490TZSSB2
EWAH490TZSLB2
EWAH490TZSRB2
8,6
EWAH530TZSSB2
EWAH530TZSLB2
EWAH530TZSRB2
10,7
EWAH600TZSSB2
EWAH600TZSLB2
EWAH600TZSRB2
8,4
EWAH690TZSSB2
EWAH690TZSLB2
EWAH690TZSRB2
13
EWAH750TZSSB2
EWAH750TZSLB2
EWAH750TZSRB2
15,4
EWAH820TZSSB2
EWAH820TZSLB2
EWAH820TZSRB2
15,4
EWAH920TZSSB2
EWAH920TZSLB2
EWAH920TZSRB2
15,4
EWAH980TZSSB2
EWAH980TZSLB2
EWAH980TZSRB2
15,3
EWAHC10TZSSB2
EWAHC10TZSLB2
EWAHC10TZSRB2
20,4
Unit model
water flow [l/s]
Standard Sound
Low Sound
Reduced sound
min
GOLD
EWAH180TZXSB1
EWAH180TZXLB1
EWAH180TZXRB1
6,9
EWAH220TZXSB1
EWAH220TZXLB1
EWAH220TZXRB1
8,3
EWAH270TZXSB1
EWAH270TZXLB1
EWAH270TZXRB1
8,3
EWAH300TZXSB1
EWAH300TZXLB1
EWAH300TZXRB1
8,3
EWAH350TZXSB2
EWAH350TZXLB2
EWAH350TZXRB2
8,7
EWAH390TZXSB2
EWAH390TZXLB2
EWAH390TZXRB2
10,7
EWAH430TZXSB2
EWAH430TZXLB2
EWAH430TZXRB2
8,5
EWAH480TZXSB2
EWAH480TZXLB2
EWAH480TZXRB2
10,7
EWAH580TZXSB2
EWAH580TZXLB2
EWAH580TZXRB2
13
EWAH620TZXSB2
EWAH620TZXLB2
EWAH620TZXRB2
12,9
EWAH670TZXSB2
EWAH670TZXLB2
EWAH670TZXRB2
12,9
EWAH710TZXSB2
EWAH710TZXLB2
EWAH710TZXRB2
15,3
EWAH760TZXSB2
EWAH760TZXLB2
EWAH760TZXRB2
12,2
EWAH820TZXSB2
EWAH820TZXLB2
EWAH820TZXRB2
15,3
EWAH930TZXSB2
EWAH930TZXLB2
EWAH930TZXRB2
20,4
EWAH990TZXSB2
EWAH990TZXLB2
EWAH990TZXRB2
15,3
