MEAN WELL RPS-65-48 Data Sheet онлайн
65W Single Output Medical Type
RPS-65 series
-
3.3
RPS 65
Output wattage
Output voltage
EN 60601-1
IEC 60601-1
8
-
Series name
File Name: -SPEC 2015-11-04RPS 65-
ApplicationsFeatures
Oral irrigator
Hemodialysis machine
Medical monitors
Sleep apnea devices
Description
Model Encoding
3"×2" miniature size
Universal AC input / Full range
Class (without FG) installationsⅡ
Medical safety approved
(2 x MOPP between primary to secondary)
Suitable for BF application with appropriate system consideration
Low leakage current <100 A μ
No load power consumption<0.1W
High efficiency up to 91%
For 1U applications
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
-30~70 wide range of operating temperature
℃
Operating altitude up to 4000 meters(Note 6.)
LED indicator for power on
3 years warranty
RPS-65 is a 65W highly reliable green PCB type medical power supply with a high power density on the 3”
by 2” footprint. It accepts 80~264VAC input and offers various output voltages between 3.3V and 48V. The
working efficiency is up to 91% and the extremely low no load power consumption is down below 0.1W.
RPS-65 is able to be used for Class (no FG) system design. The extremely low leakage current is lessⅡ
than 100 A. In addition, it conforms to international medical regulations (2*MOPP) and EMC EN55011,μ
perfectly fitting all kinds of BF rated “patient contact” medical system equipment.y
