MEAN WELL ERDN20-24 [4/5] A enclosed type redundancy module
![MEAN WELL ERDN20-24 [4/5] A enclosed type redundancy module](/views2/1674200/page4/bg4.png)
File Name:ERDN20-SPEC 2019-11-01
20A Enclosed Type Redundancy Module
Vin 1
Vin1
Vin 1
Power
Supply
AC DC-
Power
Supply
AC DC-
1. 1+1 Redundancy:
Using 1 more PSU as the redundant unit
2. 1+N Redundancy:
Using more PSUs as the redundant units to increase the reliability
3. Single Use:
Connecting only one PSU to one ERDN20 to reduce the stress of the and hence increase the reliabilityMOSFET
