MEAN WELL ERDN20-24 [5/5] A enclosed type redundancy module
![MEAN WELL ERDN20-24 [5/5] A enclosed type redundancy module](/views2/1674200/page5/bg5.png)
File Name:ERDN20-SPEC 2019-11-01
ψ3.5
5
23.5
9.4
8.25
6.88
6.88
8.1
9.3
8
9
10
11
Case No.932D Unit:mm
20A Enclosed Type Redundancy Module
Alarm1 DC OK
Alarm2 DC OK
7
DC input +Vin2
6
DC input +Vin1
DC input -Vin
82
36
99
Mating Housing
TKP DH2
TKP
or equivalent
or equivalent
Terminal
Function Connector(CN11): TKP DH2I-2X2 or equivalent
CN11
