EWWD_DZ – EWWH_DZ
D-EOMWC01405-18EN
33/47
String in the alarm list:
UnitOffEvpEntWTempSen
String in the alarm log:
UnitOffEvpEntWTempSen
String in the alarm snapshot
UnitOffEvpEntWTempSen
Sensor is shorted.
Check if sensor is shorted with a
resistance measurement.
Sensor is not properly connected (open).
Check for absence of water or humidity on
electrical contacts.
Check for correct plug-in of the electrical
connectors.
Check for correct sensors wiring also
according electrical scheme.
Reset
Notes
Local HMI
Network
6.2.4 Evaporator Water Temperatures inverted
This alarm is generated any time the entering water temperature is lower than the leaving by 1°C and at least one
compressor is running since 90 seconds.
Symptom
Cause
Solution
Unit status is Off.
All circuits are stopped with a normal
shutdown precedure.
Bell icon is moving on controller’s display.
String in the alarm list:
UnitOffEvpWTempInvrtd
String in the alarm log:
UnitOffEvpWTempInvrtd
String in the alarm snapshot
UnitOffEvpWTempInvrtd
Entering and leaving water temperature
sensors are inverted.
Check cabling of the sensors on the unit
controller.
Check offset of the two sensors with the
water pump running
Entering and leaving water pipes are
reversed
Check if the water flows in counter flow
respect to refrigerant.
Water pump operate reverse.
Check if the water flows in counter flow
respect to refrigerant.
Reset
Notes
Local HMI
Network
Auto
6.3 Unit Rapid Stop Alarms
6.3.1 Condenser Water Freeze alarm (W/C units only)
This alarm is generated to indicate that the water temperature (entering or leaving) has dropped below a safety limit.
Control tries to protect the heat exchanger starting the pump and letting the water circulate.
Symptom
Cause
Solution
Unit status is Off.
All circuits are stopped immediately.
Bell icon is moving on controller’s display.
String in the alarm list:
UnitOffCondWaterTmpLo
String in the alarm log:
UnitOffCondWaterTmpLo
String in the alarm snapshot
UnitOffCondWaterTmpLo
Water flow too low.
Increase the water flow.
Inlet temperature to the evaporator is too
low.
Increase the inlet water temperature.
Flow switch is not working or no water flow.
Check the flow switch and the water pump.
Refrigerant temperature become too low (<
-0.6°C).
Check the water flow and filter. No good
heat exchange condition into the
evaporator.
Sensors readings (entering or leaving) are
not properly calibrated
Check the water temperatures with a
proper instrument and adjust the offsets
Wrong freeze limit setpoint
The freeze limit has not been changed as
a function of glycol percentage.
Reset
Notes
Local HMI
Network
Auto
It’s required to check if the condenser has
any damage due to this alarm.
6.3.2 Condenser Water Flow Loss alarm (W/C units only)
This alarm is generated in case of flow loss to the chiller to protect the machine against Mechanical High Pressure trips.
Symptom
Cause
Solution
Unit status is Off.
All circuits are stopped immediately.
Bell icon is moving on controller’s display.
String in the alarm list:
UnitOffCondWaterFlow
String in the alarm log:
UnitOffCondWaterFlow
String in the alarm snapshot
UnitOffCondWaterFlow
No water flow sensed for 3 minutes
continuously or water flow too low.
Check the water pump filler and the water
circuit for obstructions.
Check the flow switch calibration and
adapt to minimum water flow.
Check if pump impeller can rotate freely
and has no damages.
Check pumps protection devices (circuit
breakers, fuses, inverters, etc.)
