EWWD_DZ – EWWH_DZ
D-EOMWC01405-18EN
39/47
6.5.4 Low Discharge Superheat fault
This alarm indicates that the unit has worked for too long with low discharge super heat.
Symptom
Cause
Solution
Circuit status is Off.
The circuit is switched off with the
shutdown procedure.
Bell icon is moving on controller’s display.
String in the alarm list:
CxCmp1 OffDishSHLo
String in the alarm log:
CxCmp1 OffDishSHLo
String in the alarm snapshot
CxCmp1 OffDishSHLo
EEXV is not working correctly.
It’s not opening enough or it’s moving in
the opposite direction.
Check if pump-down can be finished for
pressure limit reached;
Check expansion valve movements.
Check connection to the valve driver on the
wiring diagram.
Measure the resistance of each winding, it
has to be different from 0 Ohm.
Reset
Notes
Local HMI
Network
Auto
x 2 attempts (W/C only)
6.5.5 Suction Temperature Sensor fault
This alarm is generated to indicate that the sensor is not reading properly.
Symptom
Cause
Solution
Circuit status is Off.
The circuit is switched off with the normal
shutdown procedure.
Bell icon is moving on controller’s display.
String in the alarm list:
CxCmp1 OffSuctTempSen
String in the alarm log:
CxCmp1 OffSuctTempSen
String in the alarm snapshot
CxCmp1 OffSuctTempSen
Sensor is shorted.
Check for sensor integrity.
Check correct sensors operation
according information about kOhm (k)
range related to temperature values.
Sensor is broken.
Check if sensor is shorted with a
resistance measurement.
Sensor is not good connected (open).
Check for correct installation of the sensor
on refrigerant circuit pipe.
Check for absence of water or humidity on
sensor electrical contacts.
Check for correct plug-in of the electrical
connectors.
Check for correct sensors wiring also
according with electrical scheme.
Reset
Notes
Local HMI
Network
Auto
6.6 Circuit Rapid Stop Alarms
6.6.1 Compressor Extension Communication Error (W/C units only)
This alarm is generated in case of communication problems with the CCx module.
Symptom
Cause
Solution
Circuit status is Off.
All circuits are stopped immediately.
Bell icon is moving on controller’s display.
String in the alarm list:
Cx OffCmpCtrlrComFail
String in the alarm log:
Cx OffCmpCtrlrComFail
String in the alarm snapshot
Cx OffCmpCtrlrComFail
Module has no power supply
Check the power supply from the
connector on the side of the module.
Check if LEDs are both green.
Check if the connector on the side is tightly
inserted in the module
Module address is not properly set
Check if module’s address is correct
referring to the wiring diagram.
Module is broken
Check if LED are on and both green. If
BSP LED is solid red replace the module
Check if power supply is ok but LEDs are
both off. In this case replace the module
Reset
Notes
Local HMI
Network
Auto
6.6.2 EXV Driver Extension Communication Error
This alarm is generated in case of communication problems with the EEXVx module.
Symptom
Cause
Solution
