1000W Single Output Medical Type

File Name:MSP-1000-SPEC 2018-09-21

MSP-1000 series

Fig 3.1

4.Current Sharing

※ Difference of output voltages among parallel units should be less than 0.2V.

MSP-1000 has the built-in active current sharing function and can be connected in parallel, up to 4 units, to provide higher output power as exhibited below :

※ The total output current must not exceed the value determined by the following equation:

※ ×When the total output current is less than 5% of the total rated current, or say (5% of Rated current per unit) (Number of unit)

the current shared among units may not be fully balanced.

Maximum output current at parallel operation=(Rated current per unit) (Number of unit) 0.9××

※The power supplies should be paralleled using short and large diameter wiring and then connected to the load.

Between RC+(pin3) and RC-(pin4)

SW ON (Short)

SW OFF (Open)

Output Status

OFF

The PSU can be turned ON/OFF by using the

"Remote Control" function.

3.Remote ON-OFF Control

CN100

PSU2PSU1 PSU3 PSU4

Fig 4.1

LOAD

-V +V

+V+V +V +V

CN100 CN100CN100CN100

-V-V -V -V

10101010

9999

AUXAUX AUX AUXRC-RC- RC- RC-GNDGND GND GNDGNDGND GND GND-S-S -S -S

AUXGAUXG AUXG AUXG

RC+RC+ RC+ RC+CSCS CS CS

DC-OKDC-OK DC-OK DC-OK

+S+S +S +S

2222

CN100CN100

PSU2PSU1 PSU3 PSU4

CN100 CN100

1111
