MEAN WELL PM-05-5 [13/32] Easy modification for different size of dc plug
![MEAN WELL UHP-200-48 [13/32] Easy modification for different size of dc plug](/views2/1677224/page13/bgd.png)
‧ Flexible solution for small quantity
‧ Easy modification for different size of DC plug
‧ Off-the-shelf and no MOQ
Adaptor
GST18~60
GSM06~60
GEM06~60
GE12~40
SGA12~60
GS06/15
OWA-60U/E
GST90~120
GSM90
GST120~220
GSM120~220
OWA-90U/120U
Assembly Illustration
(Example)
Changeable DC Plug
DC PLUG-P1J-P1I
DC PLUG-P1J-P1M
DC PLUG-P1J-P1L
DC PLUG-P1J-P3A
DC PLUG-P1J-P3B
DC PLUG-P1J-P3C
DC PLUG-P1J-P4A
DC PLUG-P1J-P4B
DC PLUG-P1J-P4C
DC PLUG-P1J-P1IR
DC PLUG-P1J-P1MR
DC PLUG-P1J-P1LR
DC PLUG-P1J-P1JR
DC PLUG-P1J-R6B
DC PLUG-P1J-R7B
DC PLUG-P1J-R1B
Ordering No.
2.1x 5.5x 9.5mm
2.5x 5.5x 11mm
2.5x 5.5x 9.5mm
0.7x 2.35x 11mm
1.7x 4.0x 11mm
1.7x 4.75x 11mm
3.4x 5.5x 11x 1mm
4.4x 6.5x 11x 1.4mm
5.1x 7.4x 11x 0.6mm
2.1x 5.5x 9.5mm
2.5x 5.5x 11mm
2.5x 5.5x 9.5mm
2.1x 5.5x 11mm
KYCON KPPX-3P
KYCON KPPX-4P
5PIN DIN
Model No.
Model No.
DC PLUG-P1M-P1J
DC PLUG-P1M-P1JR
DC PLUG-P1M-R7B
2.1x 5.5x 11mm
2.1x 5.5x 11mm
KYCON KPPX-4P
2.1x 5.5x 11mm
Standard DC Plug
Standard DC Plug
KPPX-4P
Equivalent
2.5x 5.5x 11mm
R7B
P1M
P1J
Ordering No.
DC PLUG-R7BF-P1J
DC PLUG-R7BF-P1M
2.1x 5.5x 11mm
2.5x 5.5x 11mm
Ordering No.
Model No.
※ If you can't find the required DC plug in this table,
please contact MEAN WELL s sales reps.
Changeable DC Plug
Selection Guide
