MEAN WELL PM-05-5 [18/32] On board type

AC/DC

On Board Type

5~90W

Features

• Small PCB mount models

• Output voltage from 3.3V to 48V available

• Medical safety approved (2xMOPP)

• Suitable for BF application with

appropriate system consideration

• Class II power unit

• Peak power up to 110%

• EMI class B without additional components

• Low leakage current<80~300μA

• No load power consumption<0.075~0.1W

• -40~+85

C operating temperature

• Screw terminal type available (30~90W only)

• 3 years warranty

BF rated
