Features :
File Name:RKP-1U RACK SYSTEM-SPEC 2 015-02-11
NOTE
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.℃
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets
EMC directives.
5. Derating may be needed under low input voltages. Please check the static characteristics for more details.
6. Output of all the RCP-2000 modules are connected in parallel in the rack.
7. Under parallel operation of more than one rack connecting together, ripple of the output voltage may be higher than the SPEC at light load condition.
It will go back to normal ripple level once the output load is more than 10%.
8. Because of component tolerance, there is a possibility that some of units connected in parallel will reach an overcurrent limit then overloading the other
units when operating at full load condition. If overload conditions happen in parallel usage, it is suggested that derate the total output current by 10%.
SPECIFICATION - Rack System
RKP-6K1U -12□ RKP-6K1U -24□ RKP-6K1U -48□
MODEL
VOLTAGE RANGE
Note.5
MODULE
OUTPUT VOLTAGE
RACK
MAX. OUTPUT CURRENT
MAX. OUTPUT POWER
Note.6
FREQUENCY RANGE
INPUT
OUTPUT
LEAKAGE CURRENT
AC CURRENT (Typ.)FOR EACH UNIT
90 ~ 264VAC 127 ~ 370VDC
3600W 6048W
300A 126A
12V
RKP-1UI or RKP-1UT
48V
RCP-2000-12 RCP-2000-24 RCP-2000-48
47 ~ 63Hz
<3.5mA / 230VAC
13A/115VAC 7A/230VAC 16A/115VAC 11A/230VAC 16A/115VAC 11A/230VAC
SAFETY STANDARDS
WITHSTAND VOLTAGE
ISOLATION RESISTANCE
WORKING TEMP.
WORKING HUMIDITY
STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
DIMENSION
PACKING
OTHERS
UL60950-1, TUV EN60950-1 approved
-40 ~ +70 (Refer to "Derating Curve")℃
20 ~ 90% RH non-condensing
-40 ~ +85 , 10 ~ 95% RH℃
± ℃ ℃0.03%/ (0 ~ 50 )
10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
Rack 483.6*350.8*44(L*W*H)
ENVIRONMENT
I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.7KVDC
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25 / 70% RH℃
14.1Kg; 1pcs/14.1Kg/2.67CUFT
AC FAIL SIGNAL
DC OK SIGNAL
REMOTE SENSE
REMOTE ON/OFF CONTROL
AUXILIARY POWER
The isolated TTL signal out, refer to function manual
The isolated TTL signal out, refer to function manual
Compensate voltage drop on the load wiring up to 0.5V. "Local Sense"should be connected in order to get the correct output voltage if the "Remote Sense"is not used
By electrical signal or dry contact ON:short OFF:open
5V @ 0.3A, 12V @ 0.8A
FUNCTION
Adjustment of output voltage, possible between 90 ~ 110% of rated output
Logic " High" for over temperature warning, refer to function manual, isolated signal
SAFETY &
EMC
(Note 4)
OVER TEMP WARNING
OUTPUT VOLTAGE TRIM
5760W
240A
24V
The isolated TTL signal out, refer to function manual
FAN FAIL SIGNAL
2000~6000W Front End Power System
RKP-1 U Rack System
■SELECTION GUIDE
Rack: RKP-1U Whole System: RKP-6K1U --- CMU1
CMU1
I
I 12
Output voltage
CMU1: With RKP-CMU1
CMU1: With RKP-CMU1
I: AC Inlet (IEC320-C20)
I: AC Inlet (IEC320-C20)
: Without RKP-CMU1
: Without RKP-CMU1
T: Terminal block
T: Terminal block
-
-
‧
Universal AC input / Full range
‧
Holds up to 3 power modules
‧
Active current sharing up to 6000W(3 unit) in one 19" rack, 3 rack max.
can be operated in parallel (up to 9 units)
‧
PMBus serial interface
‧
IEC320-C20 or terminal block input
‧
Front-end & rectifier applications
‧
Stackable for system expansion
‧
Low profile: 1U height, 19" rack mount
‧
Hot swappable modules
‧
Output voltage trimming function
‧
3 years warranty
RCP-2000 rack power system is an advanced 19" rack-mounted power system containing up to 3 hot-swappable RCP-2000 rectifiers and
can deliver up to 6000W in the single rack. Up to 3 racks can be stacked to provide expanded total system capability up to 18,000W that
are especially suitable for the application of servers, information technology equipment, networking, telecommunications, and wide
range of industrial applications using distributed power architecture Note.8. Equipped with PMBus communication protocol, RCP-2000
rack system can be controlled or monitored by external device such as monitoring unit (RCP-CMU-1) or PC.
■ Description :
Compliance to EN61000-4-2,3,4,5,6,8,11, EN61000-6-2 (EN50082-2), heavy industry level, criteria A
Compliance to EN55022 (CISPR22) Conduction Class B, Radiation Class A ; EN61000-3-2,-3
EMC IMMUNITY
EMC EMISSION
Содержание
- 6000w front end power system 1
- Rkp 1u rack system 1
- Selection guide 1
- Specification rack system 1
- 6000w front end power system 2
- Mechanical specification rack system 2
- Rkp 1u rack system 2
- 6000w front end power system 3
- Cn500 in out connector pins function description 3
- Cn500 pin no assignment 3
- Connector pin no assignment cn rj45 8 positions 3
- Connector pin no assignment cn500 d type right angle 25 positions 3
- Jk1 in out connector pins function description 3
- Jk1 pin no assignment 3
- Rkp 1u rack system 3
- 6000w front end power system 4
- Front panel indicators corresponding signal at function pins 4
- Function manual 4
- Local sense 4
- Notice the s s have to be connected to the v v terminals locally in order to get the correct output voltage if the remote sensing is not used 4
- Output voltage trim 4
- Remote on off control 4
- Remote sense 4
- Rkp 1u rack system 4
- The psu can be turned on off together or separately by using the remote on off function 4
- The remote sense compensates voltage drop on the load wiring up to 0 v 4
- Voltage drop compensation 4
- 6000w front end power system 5
- Ac inpit voltage statusreporting 5
- Capabilities of a pmbus device 5
- Capability 5
- Command 5
- Command summary ref to pmbus rev 5
- Define data format for output voltage format linear n 9 5
- Define protection and response when an output overcurrent fault occurred 5
- Description 5
- Device address a0 a4 5
- Interface specification 5
- Iout_oc_fault_limit 5
- Of data 5
- On off function configuration 5
- On_off_config 5
- Operation 5
- Output current status reporting 5
- Output overcurrent setting value 5
- Output voltage setting value format linear n 9 5
- Output voltage status reporting 5
- Output voltage trimming value format linear n 9 5
- Pmbus communication interface 5
- R byte 5
- R w byte 5
- R w word 5
- R word 5
- Rcp 2000 support pmbus rev with maximum 100khz bus speed 5
- Read byte 5
- Remote on off control 5
- Rkp 1u rack system 5
- Status_input 5
- Status_iout 5
- Status_vout 5
- Status_word 5
- Summary status reporting 5
- Temperature status reporting 5
- The device address can be defined by using dip switch and shows below the dip switch down position is logic 1 and up position is logic 0 5
- Transaction 5
- Vout_command 5
- Vout_mode 5
- Vout_trim 5
- 6000w front end power system 6
- Rkp 1u rack system 6
