![MEAN WELL RSP-2400-48 [3/10] A 100a 50a 180 264vac](/views2/1680317/page3/bg3.png)
File Name:RSP-2400-SPEC 2017-10-31
Block Diagram
PWM fosc : 100KHz
FAN
O.V.P.
-V
+V
RECTIFIERS
&
FILTER
-S
+S
CIRCUIT
DETECTION
POWER
AUX
REMOTE
CONTROL
RC
FILTER
&
RECTIFIERS
AUX POWER
SHARING
LOAD
CS
POK
LIMITING
ACTIVE
CURRENT
INRUSH
CONTROL
I/P
SWITCHING
POWER
RECTIFIERS
FILTER
EMI
PWM
&
PFC
PFC
CONTROL
O.T.P.
O.L.P.
76
78
80
82
84
86
88
90
92
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
2400W Power Supply with Single Output
RSP-2400 series
Derating Curve
AMBIENT TEMPERATURE ( )℃
LOAD (%)
20
40
60
50
80
100
-20010203040506070
(HORIZONTAL)
Static Characteristics
INPUT VOLTAGE (V) 60Hz
100
90
80
70
60
50
LOAD (%)
180 185 190 195 200 210 220 230 240 250 264
MODEL
INPUT
12V
2000.4W 2400W 2400W
166.7A 100A 50A
180~264VAC
24V 48V
※ The curve above is measured at 230VAC.
EFFICIENCY (%)
LOAD
Efficiency vs Load (48V Model)
PFC fosc : 88KHz
