Fig. 5.2 Remove the CN3

Fig. 5.1 Insert the CN3

OL-SD

OLP

5.Select Overload Protection Type

(2)Remove the shorting connector on CN3 that is shown in Fig 5.2, the Overload Protection Type will be "continuous constant current limiting".

Overload Protection Type : constant current limiting

Overload Protection Type : constant current limiting with delay shutdown after 5 seconds

◎ +S,-S CSand on CN1 or CN2are connected mutually in parallel.

◎ Under parallel operation, the "output voltage programming" function is not available.

6.Current Sharing with Remote Sense

RSP-2400 has the built-in active current sharing function and can be connected in parallel, up to 3 units, to provide higher output power as exhibited below :

※ Difference of output voltages among parallel units should be less than 0.2V.

※ The total output current must not exceed the value determined by the following equation:

Maximum output current at parallel operation=(Rated current per unit) (Number of unit) 0.9××

File Name:RSP-2400-SPEC 2017-10-31

2400W Power Supply with Single Output

RSP-2400 series

(1)Insert the shorting connector on CN3 that is shown in Fig 5.1, the Overload Protection Type will be "constant current limiting with delay shutdown after 5 seconds,

re-power on to recover". This is the factory default.

※ The power supplies should be paralleled using short and large diameter wiring and then connected to the load.

※ ×When the total output current is less than 3% of the total rated current, or say (3% of Rated current per unit) (Number of unit)

the current shared among units may not be fully balanced.

No.1(Master)

No.2(Slave)

No.3(Slave)

Load

-V

-S

-V

AC/L

AC/N

◎ Sense lines should be twisted in pairs to minimize noise pick-up.

◎ When remote sensing is used in parallel operation, the sensing wire must be

connected only to the master unit
